Ultra high efficiency filter ULPA

超高效率過濾網ULPA，鋁製陽級處理外框及保護網，迷你摺式濾材，超高效率補集 PAO 99.9995%、99.99995% at 0.12µm。

FEATURES

Aluminum anode treatment frame and protection net, mini folding filter material, super high efficiency complement PAO 99.9995%, 99.99995% at 0.12µm.

  • Efficiency: PAO 99.9995%, 99.99995% at 0.12µm
    Standard: EN1822, Class U15 / U16
  • Durable temperature: 80ºC
    Durable humidity: 100%RH (NO Dew)
  • A large-volume air filter is also available.
  • Provide a variety of configurations to meet various strict clean requirements.
  • Suitable for clean rooms, clean workstations, aseptic operation tables and fan filter units (FFU).

※ The filter screen can be flexibly designed according to customer needs, and the material, origami thickness, filter efficiency, air volume and air inlet size can be selected.
※ Various sizes, specifications and any special functions can be customized.
※ All kinds of special customized designs, there are too many types to be uploaded, please inquire and refer to the actual performance unit.

Specification

Material, conditions of use

outer frame
Frame		 Anodized aluminum frame
Aluminum (Etruded Anodized)
filter
Media		 Glass fiber paper
Waterproof fire retardant glassfiber
Protection net
Faceguard		 Anodized aluminum mesh
Aluminum (Etruded Anodized)
Spacer
Gasket		 Neoprene
EPDM
Next material
Bond		 Epoxy Resin
PU Fire-retadant Urthane
Maximum temperature
Temperature		 80°C
Maximum humidity
Humidity% RH		 100% (without condensation)
100% (No condensation state)



Test conditions

Test method
Test Method
  • Atmospheric dust SCANNING TEST BY ATMOSPHERIC DUST
  • DOP
  • PAO photometer scan test (SCANNING TEST BY PAO)
Complement efficiency ULPA
Efficiency ULPA		 ≥ 99.999%, ≥ 99.9995%, ≥ 99.9999% (0.1µm-0.2µm)



ULPA air volume and size table (size mark: HxWxD mm)

Type
Model		 Efficiency (%)
Efficiency		 Rated air volume
Rated Capacticy (m3/min)		 Actual size
HxW mm		 Actual size
D mm		 Initial pressure loss
INITIAL P.D		 Final pressure loss
FINAL P.D
UAA
(ULPA)		 99.999
99.9995		 7.9CMM (278CFM) 570×570 50 13.5 mmH2O
(135 Pa)		 27.0 mmH2O
(275 Pa)
*Recommended value
16.6CMM (587CFM) 570×1170
4.3CMM (152CFM) 610×305
9.1CMM (321CFM) 610×610
13.9CMM (490CFM) 610×915
18.6CMM (658CFM) 610×1220 70
23.4CMM (827CFM) 610×1525
28.2CMM (996CFM) 610×1830
35.1CMM (1240CFM) 1170×1170
38.2CMM (1350CFM) 1220×1220
